Product Details:
|
| Control:: | PLC Control With Touch Screen | Cooling:: | Auto Water Or Fan |
|---|---|---|---|
| After-sales Service Provided:: | Engineers Available To Service Machinery Overseas | Supply Ability:: | 50 Set/Sets Per Month |
| Place Of Origin:: | Jiangsu, China | Condition: | New |
| High Light: | pipe reducer machine,pipe shrinking machine |
||
Technical parameter
| Type | idea-40 | idea-60 | idea-80 | idea-100 |
| Max tube(mm) | φ40*2.0 | φ60*2.0 | φ80*3.0 | φ100*3.5 |
| Max processing length(mm) | 110 | 130 | 150 | 180 |
| Oil pressure(Mpa) | 14 | 14 | 14 | 14 |
| Working speed | 100mm in3-4/s | 100mm in3-4/s | 100mm in3-4/s | 100mm in3-4/s |
| Size(cm) | 180*45*120 | 200*50*130 | 290*70*140 | 300*75*150 |
| Weight(kg) | 600 | 950 | 1600 | 1800 |
| Remark | 1.The max processing length can according to customers requirement. |
|||
Application
Tube end forming machine is widely used in numerous end forming applications and industries, such as automotive exhausts, furniture, air conditioning, among others. Forming controlled by hydraulic, clamping controlled by hydraulic. Microcomputer controller with English or any other language
