Product Details:
|
| Name: | 1/2" Diameter Copper Fin Type Heat Exchanger Use For Central Air Conditioning | Voltage: | AC110V/AC220~24V/AC380V/DC12V/DC24V,220/380v,220V/50Hz |
|---|---|---|---|
| Fin Material: | Stainless Steel | Air Volume: | 5000-24000m3/h |
| Structure: | Finned Tube | Wall Thickness: | SS304 T0.6, SS316L T0.9 |
| Weight: | 100-5000kg,50-1000kgs | Application: | Widely Used In Air Conditioning, Cold Storage, Central Air Conditioning |
| High Light: | 1/2" fin type heat exchanger,1/2" finned tube condenser,24000m3/h fin type heat exchanger |
||
| Tube Size | Fin (OD) | Fin Height | Fin Thickness | Fins Distance |
| Φ18x2 mm | Φ38 mm | 10 mm | 0.45 mm | 3 mm |
| Φ21x2 mm | Φ45 mm | 12 mm | 0.35 mm | 3 mm |
| Φ21x2 mm | Φ51 mm | 15 mm | 0.35 mm | 3 mm |
| Φ25x2 mm | Φ50 mm | 12.5 mm | 0.3 mm | 3 mm |
| Φ25x2 mm | Φ55 mm | 15 mm | 0.3 mm | 3 mm |
| Φ32x3 mm | Φ62 mm | 15 mm | 0.3 mm | 3 mm |
| Other finned tube size can be customized. | ||||
There are 2 kinds of the SS tube & fin heat exchangers, which are SS tube & Al fin type and SS tube & SS fin full SS type.
The products are applied for commercial A/C, industrial refrigeration, Gas cooler, Energy Recovery system, pollution gas recovery system,
industrial dryer, many other kinds of the refrigeration systems.
The hairpin tube can be “U” bended and straight, end to be connected by return bender.
The tube expanding and tube welding technology of SS heat exchanger are specialized, SS tube welding by orbital machinery. all the connect point welded smooth, full and nice appearance.
Detailed image
Changzhou Aidear Refrigeration Accessories Factory designs and manufactures a wide
range of fin type heat exchangers for refrigeration, industrial and special applications .
Our evaporators and condensers can be manufactured with different materials and can
work with all types of fluids and with duty up to 6000 kW.
We are prepared for the solution of different heat exchange problems, thanks to the widest
experience of technical departments able to suggest technical solutions best suited to each
customer's need .
