Product Details:
|
| Control:: | PLC Control With Touch Screen | After-sales Service Provided:: | Engineers Available To Service Machinery Overseas |
|---|---|---|---|
| Supply Ability:: | 50 Set/Sets Per Month | Place Of Origin:: | Jiangsu, China |
| Condition: | New | Tube Diameter: | 4-20mm |
| Tube Material: | Copper / Aluminum / Bundy Tube | ||
| High Light: | pipe reducer machine,tube reducing machine |
||
Specification
| NO. | Item | Data |
| 1 | Input voltage | 3 phase 4 lines, 50HZ |
| 2 | Pipe diameter range | 4-20mm |
| 3 | Working pressure | 0.5-0.6Mpa |
| 4 | Shrinking length | Normal type 5-50mm |
| 5 | Shrinking length | Extended type 10-95mm |
| 6 | Speed | 10-30 pieces / min |
| 7 | Pipe length range | 60-305mm |
| 8 | Bore control range | Φ1.9~Φ10±0.05 |
| 9 | Operation | Manual feeding, automatic shrinking |
| 10 | Power | 1.5kw |
| 11 | Dimension | 1840*600*1180mm |
1, Forming by rotary swaging process for welding process in next step.
2, Four-die design for less noise and better quality product
3, Special designed forming die ensure welding quality with less waste in next step..
4, Casted forming head housing ensure stable performance and long-life use.
5, Core-bar design to ensure the inner diameter during process.
