Copper Aluminum Bundy Tube Straightener Cutter High Accuracy Concentricity

Copper Aluminum Bundy Tube Straightener Cutter High Accuracy Concentricity
Copper Aluminum Bundy Tube Straightener Cutter High Accuracy Concentricity Copper Aluminum Bundy Tube Straightener Cutter High Accuracy Concentricity Copper Aluminum Bundy Tube Straightener Cutter High Accuracy Concentricity Copper Aluminum Bundy Tube Straightener Cutter High Accuracy Concentricity

Large Image :  Copper Aluminum Bundy Tube Straightener Cutter High Accuracy Concentricity

Product Details:
Place of Origin: CHINA
Brand Name: OEM/ODM
Certification: CE,ROHS ,ISO9001,ISO14001,
Model Number: Customized
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: wooden packing
Delivery Time: 20-25days
Payment Terms: L/C, T/T
Supply Ability: 1-3 sets per month

Copper Aluminum Bundy Tube Straightener Cutter High Accuracy Concentricity

Description
Name: Copper Aluminum Bundy Tube Straightener Cutter High Accuracy Concentricity Place Of Origin: Jiangsu, China
Type: Straightener & Cutter Voltage: 380V 50Hz
Dimension(L*W*H): 2300 X 650 X 1300 Mm Power(W): 1120
Tube Material: Copper / Aluminum / Bundy Tube Weight: 500kgs
High Light:

bundy tube straightener

,

straightening and cutting machine

Copper Aluminum Bundy Tube Straightener Cutter High Accuracy Concentricity

Specification



Parameters
Product brand OEM/ODM
Product model AD-6-16
Product voltage 380V
Product power 7.5KW
Straightening range 6-16mm
Straightening machine 5.5KW copper wire motor
Straightening speed 20m/min
Cut off range 6-16mm
Cut off the motor 2.2KW copper wire motor
Number of feed ports 6
The length of the shortest 300mm
Total Weight 500KGS
Dimensions 1300*1000*1100CM

Production Description

Copper aluminum bundy tube straightener and cutting machine is special designed for copper and aluminum tube process, which is mainly used for tube blanking before tube bending or welding process of condenser and evaporator.

Compare to normal design with two-half clamping die, we design the clamping die in three parts according to lathe chuck structure, which can minimize the tube distortion during cutting, and the clamping die changing / adjustment will be more easier.

Copper Aluminum Bundy Tube Straightener Cutter High Accuracy Concentricity 0Copper Aluminum Bundy Tube Straightener Cutter High Accuracy Concentricity 1

Main Features


◆ Three-part clamping die to minimize tube distortion, get smooth cutting end surface.
◆ High accuracy concentricity ensures to get good welding quality in following process.
◆ Chipless cutting with 360° rotary cutting and stretching with two points clamping.
◆ Straightening wheel Nylon and “U” shape rubber belt to avoid scratch on tube surface.


Parameter
Data
1
Tube Material
Copper / Aluminum / Bundy tube
2
Tube Diameter
4-20mm
3



Cutting Length
>50mm
4
Work Speed
0~60m/min, adjustable by Inverter
5
Cutting Tolerance
0.5mm/1m
6
Control System
PLC control / HMI
7
Motor Power
1.12KW
8
Electric System
380V, 50Hz, 3Phae (Customized)
9
Dimension
2300 x 650 x 1300 mm
10
Weight
460 KG


Packaging & Delivery

Packaging Details:Coil steel bundy aluminum copper tube pipe cut to length machine with chipless clean cutting is packaged within wooden case.
Port:Coil steel bundy aluminum copper tube pipe cut to length machine with chipless clean cutting is delivered Shanghai
Lead Time : 30 days

Copper Aluminum Bundy Tube Straightener Cutter High Accuracy Concentricity 2
